How SafeGraph Transformed Configuration Management (and Supercharged Spark Development)

In the early days, SafeGraph didn’t really have a formal configuration management system. And that’s very common. Things worked… until they didn’t.

Configs were spread across:

• Kubernetes ConfigMaps and environment variables
• AWS Lambda environment variables
• Hard-coded values inside application code
• Airflow’s variable store
• Databricks cluster configuration as environment variables

On a whiteboard that doesn’t sound terrible. But a few concrete problems quickly emerged:

1. No auditability
There was no reliable way to answer basic questions:
- Who changed this configuration?
- What exactly changed?
- When did it change, and why?

2. No proper review or approval flow
Updating configs often bypassed code review. People would tweak an environment variable or Airflow variable directly. That meant:
- Risky changes in production
- No pull request history
- No systematic checks or tests before applying modifications

3. Hard to share configs across applications
Common settings (like a shared API endpoint or bucket path) were duplicated:
- Slightly different values in different systems
- No clear source of truth

4. Security issues: secrets in plain text
Some credentials were hard-coded or stored in plain text. Obviously not ideal from any security or compliance perspective, especially as the company and data scale grew.

None of these problems are especially exotic. The important part is how they compound over time, especially in a data-heavy environment.

Two real incidents really highlighted why SafeGraph needed a better configuration management system.

#### 1. Customer configuration table catastrophe

A migration script had a bug that accidentally reset all rows in a critical customer configuration table to a default value.

Why was this table so important? It determined:

• Which products each customer should receive
• What data sets needed to be delivered each month

Because of the bug:

• All customer configs were wiped to defaults
• SafeGraph shipped the wrong datasets to all customers

Restoring the old state was painful:

• Restore an RDS snapshot to a new cluster
• Export the data to a file
• Import it back into the main RDS cluster
• Then re-run data deliveries for customers

The core problem wasn’t only the migration bug—it was that configurations weren’t versioned and managed like code, so rolling back config mistakes was heavy and slow.

#### 2. Hard-coded API endpoint breaks services

In another case, SafeGraph needed to update a widely used API endpoint referenced across multiple services and codebases.

But because the endpoint was hard-coded in many places:

• Engineers had to open multiple pull requests across repos
• The change required significant manual effort and coordination
• Even with all that, they still missed a few usages of the old endpoint

So when the team finally deprecated the old endpoint:

• Some applications still referenced it
• Those apps broke in production

Again, the root issue was the pattern of hard-coded configuration. It made safe, global changes extremely difficult and eroded development velocity.

At that point, it was pretty clear that SafeGraph needed a more robust, centralized approach to configuration.

At the heart of the new system is Spring Cloud Config Server, an open-source configuration service that:

• Exposes configs over an HTTP API
• Supports Git as a storage backend
• Allows clients to request configs by application, environment, and version

In practice, this meant:

1. Configurations live in a single GitHub repository
- Every application gets its own directory
- Each directory contains one or more YAML configuration files

2. Git becomes the source of truth
- All changes go through pull requests
- Code review, approvals, and CI checks can apply to configs
- History and blame (“who changed what, when?”) are built-in

3. Config resolution is environment-aware
For each service, SafeGraph keeps:
- A base configuration file
- One or more environment-specific config files (e.g. `dev`, `staging`, `prod`)

When a client requests configuration for a given application and environment, the config server:

• Loads the base config
• Merges it with the environment-specific config
• Returns the merged result

This layering has a few really nice benefits:

• Common defaults live in one place (the base file)
• Environment-specific overrides (like different endpoints or resource limits) are clean and explicit
• Teams don’t have to duplicate entire config files per environment

To be honest, that base + override pattern is simple but incredibly effective in reducing duplication and config drift across environments.

Even with a robust config server, you don’t really want every engineer hand-rolling HTTP calls to fetch configs.

To make the system easy to adopt, SafeGraph wrote client libraries in:

• Python
• Scala

These libraries:

• Handle talking to the Spring Cloud Config Server
• Accept simple parameters like application name, environment, and version
• Deserialize the YAML into typed config objects (or structured dictionaries)

The result is that application code can stay relatively clean. Instead of sprinkling HTTP logic and config parsing everywhere, engineers can do something conceptually like:

```python
config = sg_config.load(app="my-service", env="prod")
```

and get a ready-to-use configuration object. The awkward bits stay under the hood.

In the YAML configuration files, secrets are represented indirectly by their SSM Parameter Store path, rather than by the secret value itself.

For example, a config file might contain something like:

```yaml
database_password: SG_SECRET:/safegraph/prod/db/password
```

(This is a conceptual example; the exact path or casing may differ.)

Here’s how it works end-to-end:

1. The configuration key/value in YAML uses a special prefix (e.g. `SG_SECRET`).
2. The client libraries (Python/Scala) detect keys with this prefix.
3. When the app loads configuration, the library:
- Calls AWS SSM Parameter Store with the referenced path
- Fetches the actual secret value
- Transparently replaces the placeholder with the real secret in the returned config object

From the user’s perspective, they just use `config.database_password` as a normal value. They don’t have to manually integrate with SSM in every service.

This approach brings a few practical benefits:

1. No secrets in Git
- Even if someone browses the config repository, they only see secret references, not the values.

2. Fine-grained access control with IAM
Because secrets live in AWS SSM:
- You can manage access via IAM roles and policies
- Different services can be allowed to read only the parameters they need

3. Centralized secret rotation
Rotating a password or token becomes much easier:
- Update the value in SSM
- Apps read the new value on restart or next load, without any change to the YAML files

4. Keeps configuration readable and structured
You still see where secrets are used in your config hierarchy without exposing the sensitive values.

In my experience, this split of “config in Git, secrets in a managed store” is a solid default pattern for most teams building a configuration management strategy.

Launching a Spark job on EMR on EKS via its API requires a long list of parameters, including:

• Cluster or virtual cluster IDs
• Job runtime configuration
• Docker image
• Executor and driver resource settings
• Logging/config paths
• Environment variables

Previously, each engineer or service that needed to submit a job had to:

• Construct these large parameter dictionaries or JSON blobs manually
• Duplicate the same boilerplate configuration over and over

This resulted in:

• Cluttered code whenever a job was launched
• Inconsistent defaults between different teams and codebases
• A higher barrier to entry for new engineers trying to run Spark jobs

Surprisingly, this is a classic case where configuration management can drastically reduce cognitive load.

SafeGraph used the new config management system to centralize most of the EMR on EKS job configuration.

The idea was pretty simple, but powerful:

1. Define a set of default job parameters in the centralized config repo
These included things like:
- Base EMR on EKS parameters
- Recommended Spark defaults
- Shared Docker image IDs
- Logging and monitoring configuration

2. Tooling uses these defaults as a base template
When a job is launched, SafeGraph’s internal tooling:
- Loads the base configuration from the config service
- Merges in any job-specific overrides provided by the engineer
- Calls EMR on EKS with the combined set of parameters

3. Engineers only specify what’s unique to their job
Instead of passing a long, verbose set of parameters, they just provide:
- Job name
- Application code or entrypoint
- Input/output paths or core business parameters

According to the example described, this approach eliminated roughly 90% of the boilerplate configuration engineers previously had to write when submitting jobs.

Conceptually, it looks like this:

• Before: 30–40 lines of parameters per job submission
• After: A short, focused set of job-specific fields

This change:

• Made Spark development and iteration significantly faster
• Reduced configuration errors and confusion
• Standardized how jobs are launched across the company

The benefits weren’t just on the developer side. The platform team also gained much better operational control over Spark.

Using the centralized config system, they maintain a dedicated configuration file for the Spark platform itself. From that single file, they can control things like:

• The Docker image ID used for Spark jobs
• Which availability zones to use for running jobs
• Default driver and executor resource parameters
• Other platform-wide tuning settings

The key point is: these changes are now centralized and config-driven.

If the platform team wants to:

• Update the base Spark Docker image
• Change default resource allocations
• Adjust availability zones for cost or reliability reasons

They can do it by editing a single config file, going through a standard pull request, and rolling it out—without touching any user code.

As a result:

• Bug fixes can be rolled out more frequently
• New platform features or tuning changes reach all jobs consistently
• Users don’t have to update their code just because the platform evolves

In my view, this is where configuration management really shines: decoupling platform evolution from application changes.

Configs change production behavior just as much as code does.

So, where possible:

• Put configuration under version control (Git)
• Use pull requests for reviews and approvals
• Keep a consistent history of changes
• Consider adding basic validation or checks for critical config

This alone will help with auditability and safer rollouts.

The base + environment-specific layering pattern is simple but very effective.

Aim for:

• A base configuration shared across all environments
• Overrides for `dev`, `staging`, `prod` where values genuinely differ

This minimizes duplication and makes it much easier to see what’s different between environments at a glance.

Even if you’re not using AWS SSM, try to:

• Keep secrets out of Git
• Use a dedicated secrets manager or parameter store
• Reference secrets indirectly from configuration files

Then let your libraries or service layer resolve those secrets at runtime. Developers shouldn’t have to deal with raw secret values more than absolutely necessary.

If using a central config service, provide language-specific client libraries (even if they’re small wrappers):

• Hide HTTP details
• Offer a simple `load_config(app, env)` style API
• Handle secret resolution transparently

The easier it is to consume configuration, the more consistently your teams will use the system.

Configuration management isn’t just about avoiding outages.

You can also use it to:

• Define shared defaults for complex APIs (like EMR on EKS)
• Reduce boilerplate in job submission and service wiring
• Standardize best practices across different teams

The SafeGraph Spark example is a good pattern: centralized defaults + minimal overrides.

Even outside Spark, you can apply this to things like:

• API client configuration
• Background job frameworks
• Messaging systems (Kafka, SQS, etc.)
